The shower board F-BED decentralized horizontal drain 120x120x5mm is a waterproof, coated rigid foam shower system with integrated slope. It allows for efficient water drainage through the decentralized, horizontal drain. The drain plate is centrally installed and sealed to ensure reliable drainage.

This shower board is ideal for use in barrier-free showers and wet areas. It can be fully coated with liquid sealing Material according to DIN 18534-1 and is suitable for water impact class W3-l. The installation height and geometry allow for flexible adaptation by the installer.

The shower system offers a drainage performance of 42 l/min and a seal water level of 50 mm according to DIN EN 274. It is stable enough for use with wheelchairs, especially when using tiles from a size of 100 x 100 mm or 50 x 50 mm with additional glass fiber fabric.
